Couples buying guide · 7 min read
Compact couples caravans: measure the whole van
Compare five Australian couples layouts by overall travel versus body length, published tare and ATM, bed arrangement and qualified prices.
In brief
Measure the entire travelling caravan, then compare the bed and bathroom routine. The five-model table separates body and floor measurements from overall length and leaves missing prices, dimensions and ATM unconfirmed.

Decide which dimension limits your choice
A compact label may describe a body or floorplan. It does not prove a short overall towing length, a low travel height or a suitable fit in your storage space. Write down the limits that actually matter: the usable parking length, lowest opening, narrowest access point and any turn or slope on the way in.
Compare those measurements with the overall travelling length, width and height for the exact configuration. Keep body length and interior height in separate columns. Ask whether the stated travel measurements include the coupling, rear-mounted equipment, roof accessories and selected options.
- Overall travel length, including projections.
- Overall travel height with roof equipment fitted.
- Width at the widest relevant point.
- Door, hatch and service access once parked.
Five models: compare the whole footprint
The original exact-layout comparison was checked on 25 October 2026. Jayco’s tare and towball specification and the SRC-17 and Liberty SV advertised prices were rechecked on 7 November; Jayco’s NSW postcode 2000 price was checked on 19 November, and other facts retain the dated evidence in each profile. Reviewed profiles appear first; research drafts retain their missing fields and photo limitations. This is a selection exercise, not a best-caravan ranking or a tow-vehicle fit assessment.
The Liberty SV publishes external floor length, not body length; the two labels are kept separate. Avan calls its overall figure garage length. Do not derive body length from a feet label or assume all manufacturers measure the same endpoints.
Liberty SV suits someone willing to convert singles into a queen; SRC-17 provides an island queen and ensuite in a longer footprint. The 402 Double hardtop is shorter but has no ensuite and no confirmed model year or current configured price. Jayco’s selected MY26.5 layout has a postcode-specific tow-away estimate. Its fitted ATM still needs confirmation. Manta Ray 19ft needs 7.99 m of travel length; its body length and travel height are unconfirmed, and New Age’s MY26 interior tour shows the opposing dinette seats beside the kitchen.
Swipe or scroll the comparison table on a phone; keyboard users can focus the table region and use arrow keys. Follow each model for dated field evidence and open questions. Manufacturer weights are indicative, not weighed loaded units; quoted prices have different inclusions.
| Model / evidence state | Overall travel length | Body / floor length | Layout | Published tare / ATM | Advertised AUD price / conditions |
|---|---|---|---|---|---|
| Crusader Chameleon Liberty SV MY26 Editorially reviewed Manufacturer specification ↗ | 5,750 mm | Body: Not confirmed External floor: 3,815 mm (separate measurement) | Two singles zip together as a queen | Tare: 1,511 kg ATM: 2,700 kg Manufacturer figures; unit and options can vary. | A$69,204 Manufacturer standard MY26 base RRP A$69,204, checked 7 November 2026, excluding state registration. Optional upgrades and bundles cost extra; obtain a current itemised quote. Price source checked |
| Snowy River SRC-17 Editorially reviewed Manufacturer specification ↗ | 6,827 mm | Body: 5,239 mm | Queen island bed | Tare: 1,964 kg ATM: 2,500 kg Manufacturer figures; unit and options can vary. | A$64,990 Manufacturer model page advertised $64,990 tow-away nationwide on 7 November 2026 (UTC), including registration, pre-delivery and dealer delivery. Confirm the selected options and current written quote. Price source checked |
| New Age Manta Ray 19ft Couples Editorially reviewed Manufacturer specification ↗ | 7,990 mm | Body: Not confirmed | Queen bed; Café dinette; Internal ensuite | Tare: 2,250 kg ATM: 2,950 kg Manufacturer figures; unit and options can vary. | A$81,490 Manufacturer starting price A$81,490 for this 2026 standard on-road layout, checked 19 November 2026. Excludes on-road costs, dealer delivery and options. Price source checked |
| Avan Aspire 402 Double Hardtop Research draft Manufacturer specification ↗ | 5,330 mm | Body: 3,860 mm | Two berths in the 402 Double hardtop layout. | Tare: 1,150 kg ATM: 1,500 kg Manufacturer figures; unit and options can vary. | Not confirmed No current price for an exact matched configuration is confirmed. Range starting prices and dealer stock offers are not substituted for a configured quote. Price source checked |
| Jayco Starcraft 15.48-8 Research draft Manufacturer specification ↗ | 7,163 mm | Body: 4,718 mm | Sleeps 2 adults | Tare: 1,780 kg ATM: Not confirmed Manufacturer figures; unit and options can vary. | A$59,787 Indicative tow-away price for this Standard floorplan with default decor and no paid options, checked for NSW postcode 2000 on 19 November 2026. Includes GST and applicable on-road costs. Location, options and dealer charges can change the final quote. Price source checked |
Source: Crusader MY26 Chameleon Liberty SV — checked 25 October 2026
Source: Snowy River SRC-17 — checked 25 October 2026
Source: Avan 402 Double hardtop, embedded selected-layout specifications — checked 25 October 2026
Source: Jayco Starcraft 15.48-8.SC-MY26.5 Standard — checked 25 October 2026
Source: New Age Manta Ray 19ft Couples Touring — checked 25 October 2026
Test how two people use the interior
Try the bed, seats, kitchen and bathroom in the order you will use them on a normal trip. A fixed bed may save nightly setup; a convertible layout may give more daytime seating. Neither is automatically better. Look at whether one person can move around while the other cooks or rests.
Small layouts make storage decisions more visible. Open the cupboards and tunnel storage, then decide where bedding, food, shoes, outdoor gear and daily bags would go. If a bathroom or cooking area is missing from a profile, treat that as an unresolved fact until the selected floorplan or dealer confirms it.
- Can both travellers sit comfortably without converting the bed?
- Is there a usable path around the bed and to the bathroom?
- What cooking can be done inside during poor weather?
- Where will frequently used items be stored?
Keep published mass separate from suitability
The directory lists manufacturer-published tare and ATM where the exact record supports them. These are comparison points, not a towing clearance. Equipment changes, water and the actual delivered caravan can change the situation. A low advertised mass does not settle the limits of a tow vehicle, towbar, coupling or full loaded combination.
Ask for the delivered unit's plate information and the relevant vehicle and towing-equipment documents. The NSW Government's towing guidance sets out several limits to consider; the authority for the places you drive should be checked as well. Seek a competent assessment for your intended loaded setup.
- Record the source and date of every weight figure.
- Ask what equipment was included in the published tare.
- Confirm the actual unit's plate values.
- Arrange a full combination assessment before relying on a tow plan.
Compare a dated quote with the inspected van
Where CaravanScout shows a price, the note on the model profile explains its advertised context. A starting price, promotional price and indicative RRP may include different charges. Ask for an itemised written quote for the exact model year, layout, options and delivery location rather than comparing headline amounts alone.
At the inspection, measure and photograph the practical pinch points with permission. Keep a short list of what works, what compromises you accept and what remains unconfirmed. The best two-person van is the one whose actual configuration supports your routine and constraints, not the one with the shortest model name.
- Does the quote identify the exact variant and included options?
- Which delivery, registration and on-road charges are included?
- Can the dealer demonstrate travel and setup positions?
- Which dimensions still need direct confirmation?
