Family caravan floor plans: bunks and bed layouts

Compare family caravan floor plans with fixed bunks, convertible beds and exact-model examples. Check seating, bathroom access and the quoted configuration.

In brief

Start with the floor plan for the exact model year and bunk configuration. Count beds that stay made up separately from sleeping places converted from seating, then check bathroom access and usable seats with everyone’s beds ready. The four examples below show which beds can stay made up while the family uses the table.

Illustrative caravan scene accompanying the family bunk layout guide
Illustrative category image, not a reviewed model or a floorplan.

Four family layouts to compare on paper and in person

These are examples of different sleeping arrangements, not a ranking or a complete market survey. Follow each manufacturer link, match the model year and configuration, and mark every sleeping place. Manufacturer illustrations describe a layout; they do not confirm fitted equipment, adult-sized sleeping capacity or the comfort of your household.

The Fraser link opens an exact 2026 layout illustration at the manufacturer. Jayco’s range selector needs the 19.61-3.SC-MY26.5 Standard configuration; other bunk and dinette options are separate. MDC’s linked model page explicitly describes its two bunks and dinette conversion. Floor-plan artwork is linked rather than reproduced here.

All four profiles have been editorially reviewed. Crusader publishes mattress sizes for the Bunkie’s queen bed and two bunks. For the Jayco, Port Macquarie stock 15176 shows exactly which beds come with the quoted van. These details let you compare who can sleep where before arranging an inspection.

Retreat Fraser 180B viewed from the entry side in the manufacturer gallery
Manufacturer exterior

Editorially reviewed

Retreat Fraser 180B

Bed layout: The 2026 180B illustration shows one double bed and two bunks. No extra convertible sleeping place is counted in this record.

Open the manufacturer’s 2026 Fraser 180B floor plan ↗

Advertised model price$147,740

Stated berths
4
Published ATM
3,500 kg
Manufacturer-listed length
9,400 mm

Why inspect it: A family comparing a front double bed with two rear bunks and an internal bathroom. Trace the bathroom route while the bunks are occupied.

Trade-off to check: Four is our editorial count of the beds in the illustration, not a manufacturer capacity guarantee. The 180B cooking exception specifies a portable induction cooktop rather than the range’s four-in-one unit; ask for a demonstration.

Price conditions and source

Manufacturer page advertises $147,740 for the 2026 Fraser 180B. Inclusions, delivery and on-road conditions are not specified there; request a dated itemised quote.

Price checked . Manufacturer price source ↗

Crusader Lifechanger Bunkie caravan in an official studio photograph
Manufacturer exterior

Editorially reviewed

Crusader Lifechanger Bunkie MY26

Bed layout: Manufacturer standard layout: up to four sleeping places, a queen main bed published as 6 ft 2 in × 5 ft 0 in and two bunks each 6 ft 0 in × 2 ft 2 in. No additional converted seating place is counted.

Read the manufacturer’s MY26 Bunkie capacity and bed-size table ↗

Advertised model price$83,433

Stated berths
4
Published ATM
3,200 kg
Travel length
8,325 mm

Why inspect it: A family wanting a queen main bed and two stated bunks in the standard four-place MY26 layout. Compare access to the main bed, bunks, bathroom and L-shaped seating with everyone inside.

Trade-off to check: The manufacturer lists an on-road model, not an off-road specification. The two bunks are narrower than the main queen: confirm each occupant’s space and the manufacturer’s use limits. Illustrations may show prototype finishes or options; match the supplied unit rather than assuming the photo proves its equipment.

Price conditions and source

Manufacturer standard MY26 base RRP A$83,433, checked 25 October 2026, excluding state registration. Optional upgrades and bundles cost extra; obtain a current itemised quote.

Price checked . Manufacturer price source ↗

MDC XT17HRT+ MKIII caravan on grass with its awning and exterior kitchen deployed
Manufacturer exterior

Editorially reviewed

MDC XT17HRT+ MKIII

Bed layout: Manufacturer description: main bed, two single bunks and a convertible dinette. Five stated berths does not mean five permanent beds.

Read the manufacturer’s XT17HRT+ MKIII sleeping layout ↗

Advertised model price$89,990

Stated berths
5
Published ATM
3,500 kg
Travel length
7,010 mm

Why inspect it: A family that can use two bunks plus an extra place made by converting the dinette. Compare the seating available before and after that conversion.

Trade-off to check: On the 2025 XT17HRT+ MKIII, setting up the fifth berth takes the dinette out of use. Ask for the mattress dimensions and try the conversion with the table and cushions supplied.

Price conditions and source

MDC listed the XT17HRT+ MKIII from $89,990 on 19 November 2026 before freight, registration and government charges. Its $79,990 and $84,990 showroom deals apply to designated stock. Request the VIN, fitted equipment and total drive-away price in writing.

Price checked . Manufacturer price source ↗

Jayco Starcraft 19.61-3 caravan viewed from the front and door side
Manufacturer exterior

Editorially reviewed

Jayco Starcraft 19.61-3 Touring (stock 15176)

Bed layout: The MY26.5 Standard model at Port Macquarie has a front double, two rear bunks and a café dinette. The four fixed places are counted for this build. Its registered tare is 2,145 kg and its ATM is 2,745 kg.

See Jayco’s Port Macquarie stock 15176 and its interior photographs ↗

Advertised model price$74,839

Stated berths
4
Published ATM
2,745 kg
Travel length
7,810 mm

Why inspect it: A family of four wanting to leave the front bed and two rear bunks made up while using the facing dinette seats.

Trade-off to check: Jayco lists two additional places for this floorplan. The seller does not identify a converter kit on stock 15176. If you need a fifth or sixth berth, ask to see the complete bed made up and measure it.

Price conditions and source

A$74,839 drive-away advertised by Watsons Caravans Port Macquarie for stock 15176 on 20 November 2026. Confirm availability, inclusions and the drive-away total for your registration address.

Price checked . Manufacturer price source ↗

Source: Retreat: exact 2026 Fraser 180B layout illustration

Source: Retreat: Fraser 180B model and cooking exception

Source: MDC: XT17HRT+ MKIII sleeping description

Source: Jayco: Starcraft MY26.5 floor-plan selector and Standard capacity

Source: Crusader MY26 Lifechanger Bunkie: standard capacity and bed dimensions, checked 7 November 2026

Source: Jayco Australia | Starcraft 19.61-3 Touring stock 15176

Source: Australian Register of Approved Vehicles | Port Macquarie chassis ED2779

Compare family bunks with a couples layout

For a family of four, start with two permanent bunks and an adult bed. A couple may use the same space differently: access down both sides of an island bed or two separate singles can matter more. Open the configurations together to compare the trade-offs and follow each price back to its source.

Two family bunk layouts and a couples island-bed layout · current catalogue evidence
Model / evidence stateOverall travel lengthBody / floor lengthLayoutPublished tare / ATMAdvertised AUD price / conditions
Crusader Lifechanger Bunkie MY26

Editorially reviewed

Manufacturer specification ↗
8,325 mmBody: Not confirmed

External floor: 6,475 mm (separate measurement)

Queen bed and two bunks (manufacturer table)Tare: 2,200 kg

ATM: 3,200 kg

Manufacturer figures; unit and options can vary.

A$83,433

Manufacturer standard MY26 base RRP A$83,433, checked 25 October 2026, excluding state registration. Optional upgrades and bundles cost extra; obtain a current itemised quote.

Price source checked
Retreat Fraser 180B

Editorially reviewed

Manufacturer specification ↗
Unconfirmed. Listed length 9,400 mm, endpoints unspecified.Body: Not confirmedTwo rear bunks; Front double bedTare: 2,830 kg

ATM: 3,500 kg

Manufacturer figures; unit and options can vary.

A$147,740

Manufacturer page advertises $147,740 for the 2026 Fraser 180B. Inclusions, delivery and on-road conditions are not specified there; request a dated itemised quote.

Price source checked
Snowy River SRC-17

Editorially reviewed

Manufacturer specification ↗
6,827 mmBody: 5,239 mmQueen island bedTare: 1,964 kg

ATM: 2,500 kg

Manufacturer figures; unit and options can vary.

A$64,990

Manufacturer model page advertised $64,990 tow-away nationwide on 7 November 2026 (UTC), including registration, pre-delivery and dealer delivery. Confirm the selected options and current written quote.

Price source checked

Separate sleeping capacity from fixed beds

A published capacity can combine a parent bed, bunks and places made by converting a dinette or lounge. Start by drawing every sleeping position on the exact floorplan. Mark which beds stay ready during the day, which need furniture moved, and whether a stated place is an adult-sized bed or a child's bunk. If the page does not say, leave it unconfirmed.

Some ranges offer two or three bunks as different options. A five-place headline can describe an optional configuration rather than the van photographed or quoted. Ask the dealer to name the layout code and identify every included bed in writing. Compare that answer with the manufacturer's current floorplan and the specific unit you inspect.

  • How many fixed bunks are in this exact configuration?
  • Are any extra places converted from seating?
  • What are the mattress length, width and safe-use guidance for each bunk?
  • Can the beds remain made up while the family uses the dinette?

Walk through a wet-weather day

Stand in the van with the beds, bathroom door and table in their normal positions. Work out where everyone can sit, where bags and wet shoes will go, and whether a person can reach the bathroom without climbing over another bed. Try the fridge and storage with the bunks occupied.

A layout that sleeps the family may still have only two comfortable daytime seats. Think about meals, homework, early bedtimes and how one person cooks while others move around. Use those routines as a better comparison than a feature list alone.

  • Count usable seats with beds set up.
  • Open the bathroom and kitchen storage while someone sits at the table.
  • Check privacy and light for children who sleep earlier.
  • Identify a place for each person's everyday items.

Compare the quoted build, not a range average

A family option can alter equipment, mass and available storage. Put the model year, layout code, bunks, batteries, water tanks and other selected options beside the published tare and ATM. Ask which figures are estimates for a range and which describe the actual unit. Do not use a directory ATM figure as a tow-vehicle match assessment.

The ACCC has warned against presenting estimated reference caravan weights as precise values for individual units. For a purchase decision, obtain the relevant plate and written figures for the van being supplied, then seek a qualified assessment of the whole towing combination if needed.

  • Record the exact model year and bunk option on the quote.
  • Ask for the actual caravan's compliance-plate details.
  • Confirm whether tanks, batteries and accessories are included in stated weights.
  • Keep price inclusions and on-road costs beside the weight information.

Source: ACCC: caravan industry warned against misleading price and weight claims

Take the family to the inspection

If practical, let the people who will use the bunks try the steps, reading lights, ventilation and access to their own storage. Check the roof and window positions around each mattress. A photograph or floorplan cannot show every reach, headroom or privacy issue for your household.

Before paying a deposit, ask the dealer to demonstrate both travel and campsite arrangements and provide an itemised, dated quote. Keep unresolved questions beside each model in your shortlist rather than treating silence as a yes.

  • Who can climb into each bunk comfortably?
  • Where do bedding and toys go during travel?
  • What must be moved before leaving the campsite?
  • Which layout details need written confirmation?

Turn a floor plan into a useful three-van comparison

Use Compare beside the examples to select up to three vans, then open the comparison table. Begin with bed layout and berths, bathroom, travel dimensions, tare and ATM. Return to each profile for the exact source notes and dealer questions. Missing figures stay Not confirmed; a floor plan or published ATM does not establish a tow-vehicle match.

The documented-bunk search below excludes unknown selected bunk criteria, while the four-or-more search also requires a recorded berth total. It does not require every weight or price to be known. If you want to see unresolved candidates too, use the inclusive family search and keep those questions on your inspection list.
